Product Information:
APPLICATIONS: Barret, C-Iton, Deutz Allis, Ford Tractors, Fuji, Honda, Ishikawajima Tractors, John Deere Utility Vehicle, Kawasaki Engines, Komatsu, Massey Ferguson Tractors, New Holland Tractors, Nissan, Onan, Perkins Diesel, TCM Lift Trucks, Toyosha Tractors, Yanmar Tractors, Yanmar Marine.
STARTER #’S: S108-72, S108-72A, S108-76, S108-76A, S108-79, S108-83, S108-83A, S108-85, S108-86, S108-91, S108-95, S108-96A; S114-146, S114-160D, S114-160E, S114-160F, S114-161E, S114-161F, S114-162D, S114-163, S114-164, S114-170, S114-170B, S114-170E, S114-171, S114-171A, S114-171D, S114-172A, S114-172D, S114-172E, S114-173F, S114-180, S114-180F, S114-181, S114-182G, S114-218A, S114-229E, S114-229F, S114-254E, S114-301, S114-353, S114-381, S114-382, S114-446; S12-62*; S13-32, S13-47, S13-47A, S13-50, S13-50A, S13-61A*, S13-64, S13-69.
LESTER #’S: 16194, 16203, 16205, 16207, 16209, 16211, 16269, 16246, 16512, 16579, 16580, 16701, 16710, 16711, 16733, 16770, 16772, 16773, 16805, 16812, 16986, 17056, 17300, 17305, 18052, 18206, 18211, 18289, 18309.
NOTE: *Requires Male Spade. Used with 03915 Mobile Contact. Contact Surface is 5.5 mm from Bottom. Similar to 03525 except 03525 has Contact Surface 6.7 mm from Bottom.
Manufacturer: HITACHI
IAT Product Number: 03501
Original Numbers: SERVICING: Hitachi: 2108-4823, 2114-37001, 2114-47001, 2114-57001, 2114-57504, 2114-57508, 2114-77004, 2114-87004, 2114-97503, 2130-17002, 2130-27001, 2130-47001, 2130-6700; IAT: 02518, 02520.
Additional Information: Voltage: 12V, Cap Design: CRIMPED, Contacts Depth: 5.4 mm, Battery Terminal Length: 17.0 mm, Battery Terminal: M8 x 1.25, Motor Terminal: M8 x 1.25, Switch Terminal: Male Spade.
Related Items: 02518, 02520, 03915
