Product Information:
APPLICATIONS: Mazda B2200 Pickup, GLC Wagon, 626, Mercury Tracer, Capri. Mitsubishi DD Starters.
STARTER #?S: M3T20781, M3T22381, M3T22781, M3T24081, M3T24485, M3T24486, M3T30281, M3T30282, M3T30381, M3T32081, M3T32382, M3T32781, M3T32781ZC, M3T32782, M3T33585, M3T33586, M3T34081, M3T34082.
LESTER #?S: 16527, 16708, 16728, 16741, 16742, 33128.
COMPONENTS: Cap – 03520; Mobile Contact – 03925; Stationary Contact – 03980.
NOTES: Contact Surface is 7.8 mm from Bottom of Cap.
Manufacturer: MITSUBISHI
IAT Product Number: 02562
Original Numbers:?Mitsubishi: M371X31271, M371X33371, SB512F, SB533F; Mazda: 8218-24-760, 8937-24-760; WAI: 66-8303.
Additional Information: Voltage: 12V, Body OD: 52.0 mm, Cap Design: CRIMPED, Plunger Type: REMOVABLE, Mount Type: 3 Hole, Mounting Threads: M6 x 1.0, Battery Terminal: M8 x 1.25, Motor Terminal: M8 x 1.25, Switch Terminal: Male Spade, Relay Terminal: Female Spade w/ Lead;
Related Items: 03520, 03925, 03980
