Product Information:
APPLICATIONS: Allis Chalmers Lift Trucks, Caterpillar Lift Trucks, Case Tractors, Chrysler, Clark Lift Trucks, Cub Cadet Tractors, Eaton Lift Trucks, Hyster Lift Trucks, IHC Utility Tractors, Mazda, Mitsubishi Automotive, Mitsubishi Marine, Nissan Forklifts, Suzuki, Toro Mowers, Yale Lift Trucks. Mitsubishi DD / OSGR Starters.
LESTER #’S: 16497, 16514, 16524, 16708, 16720, 16720, 16793, 16793, 16795, 16796, 16947, 17097, 17110, 17141, 17515, 17556, 18248, 18968, 30548.
NOTE: Used on Late Version Crimp Style Solenoid. Used with 03980 Stud. Same as 03515 (Shallow Version) 5.2 mm between Edgeand Contact.
Manufacturer: MITSUBISHI
IAT Product Number: 03531
Original Numbers: SERVICING: Mitsubishi: M371X00171, M371X00372, M371X16171, M371X30371, M371X50171, M371X55871, MD602074, MD602879, MD607170, MD607434, MD607549, MM502461, MM502465; IAT: 02501.
Additional Information: Voltage: 12V, Cap Design: CRIMPED, Contacts Depth: 5.2 mm, Battery Terminal: M8 x 1.25, Motor Terminal: M8 x 1.25, Switch Terminal: Male Spade.
Related Items: 02501
